ISOFIRE LZ
REI 30, REI 60 wooden fire door
Isofire LZ is a fire rated wooden doors system, classified 30’ to 60’. Single or double, blind or glazed, with side and transom panels.
The Isofire LZ system is tested according to EN 1634-1
SPECIFICATIONS:
Fire resistance: EI 30′ – EN 1634-1
Thickness Frame/Leaf: 40 mm. leaf thickness 58 mm
Hinge: Visible
Arrangement: 1 single leaf, blind
Sound reduction: Rw 35 dB – UNI ISO 140-3
Supporting construction: Rigid or flexible
Optional HW items: Panic lock, electric stike, concealed door clooser
Decorations: Deep pr light grooves mouldings
legno
laccato
tss
SPECIFICATIONS:
Fire resistance: EI 30′ EN 1634-1
Thickness Frame/Leaf: 40 mm. leaf thickness 58 mm
Hinge: Visible
Arrangement: 1 single leaf, blind
Sound reduction: Rw 41 dB – UNI ISO 10140-2
Supporting construction: Rigid or flexible
Optional HW items: Panic lock, electric stike, concealed door closer
Decorations: Deep or light grooves, mouldings
SPECIFICATIONS:
Fire resistance: REI 30′ – UNI 9723
Thickness frame/leaf: 40 mm. leaf thickness 50 mm
Charniere: Visible
Arrangement: 1 single leaf, blind
Sound reduction: Rw 30 dB – UNI ISO 140-3
Supporting construction: Rigid or flexible
Optional HW items: Panic lock, electric stike
Decorations: Deep or light grooves, mouldings
SPECIFICATIONS:
Fire resistance: EI 90′ -EN 1634-1
Thickness frame/leaf: 70 mm. leaf thickness 80 mm
Hinge: Visible
Arrangement: Single or double
Planarity Frame/Leaf: Pulling side/Pushing side
Sound reduction: –
Supporting construction: Rigide or flexible
Optional HW items: Panic lock/Concealed door closer
Decorations: Deep or light grooves, mouldings, Sheet metal covering
