ISOFIRE LZ
Acoustic fire door REI 30, REI 60
Isofire LZ is a fire rated wooden doors system, classified 30’ to 60’. Single or double, blind or glazed, with side and transom panels.
The Isofire LZ system is tested according to EN 1634-1
FEATURES:
Fire resistance: EI 30′ – EN 1634-1
Thickness Frame/Leaf: 40 mm. leaf thickness 58 mm
Hinge: Visible
Arrangement: 1 single leaf, blind
Sound reduction: Rw 35 dB – UNI ISO 140-3
Supporting construction: Rigid or flexible
Optional HW items: Panic lock, electric stike, concealed door closer
Decorations: Deep or light grooves, mouldings
legno
laccato
tss
FEATURES:
Fire resistance: EI 30′ – EN 1634-1
Thickness Feame/Leaf: 40 mm. leaf thickness 58 mm
Hinge: Visible
Arrangement: 1 single leaf, blind
Sound reduction: Rw 41 dB – UNI ISO 10140-2
Supporting construction: Rigid or flexible
Optional HW items: Panic lock, electric stike, concealed door closer
Decorations: Deep or light grooves, mouldings
FEATURES:
Fire resistance: REi 30′ – UNI 9723
Thickness Frame/Leaf: 40 mm. leaf thickness 58 mm
Hinge: Visible
Arrangement: 1 single leaf, blind
Sound reduction: Rw 30 dB – UNI ISO 140-3
Supporting construction: Rigid or flexible
Optional HW items: Panic lock, electric stike
Decorations: Deep or light grooves, mouldings
SPECIFICATIONS:
Thickness Frame/Leaf: 40 mm. leaf thickness 58 mm
Hinge: Visible
Arrangement: 1 single leaf, blind
Sound reduction: Rw 35 dB – UNI ISO 10140-2
Supporting construction: Rigid or flexible
Optional HW items: Panic lock, electric stike, concealed door closer
Decorations: Light grooves, mouldings
